Tunnel Systems · Continuous Tunnel Line
Tunnel Finisher — Garment Finishing
Multi-compartment continuous batch washing with membrane press, pass-through drying and automated loading/shuttle conveyors — up to 90% man-free.
Technical Specifications
| Capacity (Piece/Hour) | 400 |
|---|---|
| Motor Power (Kw) | 20 |
| Heating Type | Steam |
| Width (mm) | 6.300 |
| Depth (mm) | 2.100 |
| Height (mm) | 3.000 |
| Weight (Kg) | 3.200 (7,055 lb) |
Features
- 8–16 compartments, 60–80 kg per compartment
- Bottom transfer system between compartments
- 10 Bar steam operating pressure
- 3-tank water recovery system
- Smart weight measurement — proportional water, detergent & energy
- Insulated structure — minimal heat & energy loss
- PLC controlled, 15" touch screen panel
- 100 programs and 100 customer records
- Adjustable compartment-transfer and total washing times
- Remote access for parameter & program uploading
- Full reporting system
- Central control system managing the whole line
