Tunnel Systems · Continuous Tunnel Line
Tunnel Tumble Dryer
Multi-compartment continuous batch washing with membrane press, pass-through drying and automated loading/shuttle conveyors — up to 90% man-free.
Technical Specifications
| Heating Type | Gas |
|---|---|
| Loading Capacity (Kg) | 60 (132 lb) |
| Inner Drum Volume (lt) | 1.550 (409 gal) |
| Motor Power (Kw) | 1,5 |
| Fan Motor Power (Kw) | 5,5 |
| Gas Thermal Power (Kcal) | 80.000 |
| Width (mm) | 1.950 |
| Depth (mm) | 2.285 |
| Height (mm) | 4.130 |
| Weight (Kg) | 2.500 (5,512 lb) |
Features
- 8–16 compartments, 60–80 kg per compartment
- Bottom transfer system between compartments
- 10 Bar steam operating pressure
- 3-tank water recovery system
- Smart weight measurement — proportional water, detergent & energy
- Insulated structure — minimal heat & energy loss
- PLC controlled, 15" touch screen panel
- 100 programs and 100 customer records
- Adjustable compartment-transfer and total washing times
- Remote access for parameter & program uploading
- Full reporting system
- Central control system managing the whole line
